VIP Preferred Redirect Withdrawal
VIP Preferred Redirect Withdrawal allows to withdraw to accounts participating in the VIPPreferred program.
The following method IDs are covered in this section:
ID | Name | Credit/Debit State |
---|---|---|
448 | VIPPreferred Redirect Withdrawal | WithdrawnByProvider (20) |
Payment method interaction type: Redirection to External Payment Provider (see Interaction Types).
With PavilionPayments VIP Preferred program, customers are given a 7-day revolving ACH/check-cashing limit, which allows guests to cash checks at all gaming establishments that participate in the VIP Preferred Network.
Flow overview
The flow for VIPPreferred Redirect Withdrawal is as follows:
- The merchant may call AccountInquiry through getPaymentInputDataList to get user limits. This step is optional.
- The merchant should call initiatePaymentRequest including a already existing paymentAccountID.
- In the response PXP will return an sessionID in state InitiatedByProvider.
- The merchant should invoke the VIPPreferred SDK by executing JavaScript on his cashier page. A basic HTML page is available for testing.
- After the user completes steps in the SDK, the user is redirected back to the merchant.
- PXP will receive a notification from PavilionPayments and will send a notification to the merchant, indicating also if the patron is eligible for a instant payment.
- Once the notification has been set (for state ApprovedByProvider), the payment waits in state PendingOnConfirmation.
- The merchant should approve or abort the payment by sending the executePaymentAction call.
On approval, the merchant should also indicate if the withdrawal should be sent as ACH, SDA or INP payment. - The payment will reach it´s final state WithdrawnByProvider resp. AbortedOnProvider or any applicable error state.
Redirect Integration
Currently not supported.
Backend2BackendIntegration - Account Inquiry
Before doing a deposit or withdrawal with the VIP Preferred product, the merchant should - when the customer selects the payment option - perform an Account Inquiry through the getPaymentInputDataList as described below.
User enrolled in the VIP Preferred Network
If the user is enrolled, PXP Financial returns the payment account with the VIP card number and various details about the account.
User may already be enrolled in the VIP Preferred Network
When the user is not yet enrolled, an error response will be returned.
Please see the description of the Account Inquiry here.
Backend2BackendIntegration - Withdrawal initiation for existing users
For existing users that are already enrolled to the VIP Preferred program, the merchant already has a PaymentAccountID.
The following should be provided in initiatePaymentRequest
The following parameters can be provided in initiatePaymentRequest.specificPaymentData:
key (value type, account type, required) | value |
---|---|
returnURL (string, optional) | ReturnURL |
androidPackageName (string, optional) | Android package to return control to. e.g. "com.pavilionpay.igaming" This field used with Plaid and is required if using the link_token to initialize the link on Android. |
Example initiatePaymentRequest:
<?xml version="1.0" encoding="utf-8"?>
<initiatePaymentRequest xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance xmlns:xsd=http://www.w3.org/2001/XMLSchema xmlns=http://www.cqrpayments.com/PaymentProcessing>
<merchantID>{{merchant}}</merchantID>
<shopID>{{shop}}</shopID>
<merchantTransactionID>{{merchantTransactionID}}</merchantTransactionID>
<paymentMethodID>448</paymentMethodID>
<amount currencyCode="USD">40.01</amount>
<userID>JADLANG1</userID>
<userIP>127.0.0.1</userIP>
<userSessionID>742f374a-08ec-4b1d-ad13-8acf6005ec6f</userSessionID>
<creationTypeID>1</creationTypeID>
<specificPaymentData>
<data xsi:type="keyStringValuePair">
<key>returnURL</key>
<value>https://www.onlinebettingportal.com/success</value>
</data>
<data xsi:type="keyStringValuePair">
<key>androidPackageName</key>
<value>com.pavilionpay.igaming</value>
</data>
</specificPaymentData>
<paymentAccountID>8a823aca-e95e-4daf-8db3-766cff1351bf</paymentAccountID>
</initiatePaymentRequest>
Example initiatePaymentResponse:
<initiatePaymentResponse xmlns=http://www.cqrpayments.com/PaymentProcessing
xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance>
<payment
xsi:type="paymentWithPaymentAccount">
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShopProvider</shopID>
<paymentMethod>
<key>448</key>
<value>VIPPreferred Redirect Withdrawal</value>
</paymentMethod>
<merchantTransactionID>hc-20240620-111007</merchantTransactionID>
<paymentID>53c54c63-bf96-430c-9ef0-5358ea0c8dbc</paymentID>
<userID>JADLANG1</userID>
<paymentProvider>
<key>213</key>
<value>Pavilionpay</value>
</paymentProvider>
<amount currencyCode="USD">40.01</amount>
<creationType>
<key>1</key>
<value>User</value>
</creationType>
<userIP>127.0.0.1</userIP>
<state>
<id>8510cfdc-0258-48d5-a8ad-2905af8b49d9</id>
<definition>
<key>3</key>
<value>InitiatedByProvider</value>
</definition>
<createdOn>2024-06-20T09:10:09.8882273Z</createdOn>
<paymentStateDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderResponseCode</key>
<value>0</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</detail>
</paymentStateDetails>
</state>
<isExecuted>false</isExecuted>
<baseAmount currencyCode="EUR">30.06</baseAmount>
<paymentDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderSessionKey</key>
<value>7031214d-f3e3-47cf-9a80-f8c4a305f544</value>
</detail>
<detail xsi:type="keyDateTimeValuePair">
<key>ProviderSessionExpireOn</key>
<value>2024-06-20T09:20:09</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>ProviderExternalID</key>
<value>10002891</value>
</detail>
</paymentDetails>
<paymentAccount>
<paymentAccountID>8a823aca-e95e-4daf-8db3-766cff1351bf</paymentAccountID>
<details>
<detail xsi:type="keyStringValuePair">
<key>accountNumber</key>
<value>7210961825</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerFirstname</key>
<value>JADWIGA</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerLastname</key>
<value>LANGLEY</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerTelephoneNumber</key>
<value>3126123087</value>
</detail>
</details>
</paymentAccount>
</payment>
</initiatePaymentResponse>
The following fields will be returned in initiatePaymentResponse:
Field | Description |
---|---|
ProviderSessionKey | Session ID created by Pavilion that is used for deposit transactions |
ProviderSessionExpireOn | Expiration of the session which is 10 minutes from time the session is created |
When the initiation of the payment fails, the payment will be moved to either InitiateErrorReportedByProvider or InitiateRefusedByProvider.
The InitiateErrorReportedByProvider state will include the details ProviderErrorResponseCode, ProviderErrorResponseMessage and AdditionalProviderErrorResponseMessage (the last one not yet included in the sample notification below).
The InitiateRefusedByProvider state will include the details ProviderResponseCode, ProviderResponseMessage _and _AdditionalProviderResponseMessage (the last one not yet included in the sample notification below).
Example initiatePaymentResponse for initiateErrorReportedByProvider (with validation error returned by provider):
<initiatePaymentResponse xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<payment
xsi:type="paymentWithPaymentAccount">
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShop</shopID>
<paymentMethod>
<key>448</key>
<value>VIPPreferred Redirect Withdrawal</value>
</paymentMethod>
<merchantTransactionID>dd07474a-2755-4777-b3f5-3556de96c431</merchantTransactionID>
<paymentID>3d80e487-11b3-4709-955b-3509cdde7055</paymentID>
<userID>VIPPreferredWithdrawalExistingPA</userID>
<paymentProvider>
<key>213</key>
<value>Pavilionpay</value>
</paymentProvider>
<amount currencyCode="USD">15.99</amount>
<creationType>
<key>1</key>
<value>User</value>
</creationType>
<userIP>127.0.0.1</userIP>
<state>
<id>226b3dda-fc3b-4e9f-8c7d-7dba20688285</id>
<definition>
<key>4</key>
<value>InitiateErrorReportedByProvider</value>
</definition>
<createdOn>2024-06-20T09:18:04.1421783Z</createdOn>
<paymentStateDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderErrorResponseCode</key>
<value>91</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>ProviderErrorResponseMessage</key>
<value>Format error.</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AdditionalProviderErrorResponseMessage</key>
<value>Unable to process your request at this time. Please contact CAMS at 1-800-500-1973 for support using error code E-91.</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</detail>
</paymentStateDetails>
</state>
<isExecuted>false</isExecuted>
<baseAmount currencyCode="EUR">12.01</baseAmount>
<paymentDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderExternalID</key>
<value>10002893</value>
</detail>
</paymentDetails>
<paymentAccount>
<paymentAccountID>d1e93745-3528-461e-87de-28554d1810be</paymentAccountID>
<details>
<detail xsi:type="keyStringValuePair">
<key>accountNumber</key>
<value>7210956515</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerFirstname</key>
<value>Sherlock</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerLastname</key>
<value>Holmes</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerTelephoneNumber</key>
<value>12132378999</value>
</detail>
</details>
</paymentAccount>
</payment>
</initiatePaymentResponse>
Example initiatePaymentResponse for InitiateErrorReportedByProvider (without validation error):
<initiatePaymentResponse xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<payment
xsi:type="paymentWithPaymentAccount">
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShop</shopID>
<paymentMethod>
<key>448</key>
<value>VIPPreferred Redirect Withdrawal</value>
</paymentMethod>
<merchantTransactionID>708e787d-e287-4645-93ab-e590434fce0c</merchantTransactionID>
<paymentID>ddab6abb-6a80-45b0-8558-0db28769b2c2</paymentID>
<userID>VIPPreferredWithdrawalExistingPA</userID>
<paymentProvider>
<key>213</key>
<value>Pavilionpay</value>
</paymentProvider>
<amount currencyCode="USD">16.99</amount>
<creationType>
<key>1</key>
<value>User</value>
</creationType>
<userIP>127.0.0.1</userIP>
<state>
<id>7d21bb61-0977-46ce-97b7-a37e218f78a0</id>
<definition>
<key>4</key>
<value>InitiateErrorReportedByProvider</value>
</definition>
<createdOn>2024-06-19T16:34:48.0046797Z</createdOn>
<paymentStateDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderErrorResponseCode</key>
<value>400</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>ProviderErrorResponseMessage</key>
<value>"Error converting value depos to type X"</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</detail>
</paymentStateDetails>
</state>
<isExecuted>false</isExecuted>
<baseAmount currencyCode="EUR">12.77</baseAmount>
<paymentDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderExternalID</key>
<value>10002854</value>
</detail>
</paymentDetails>
<paymentAccount>
<paymentAccountID>d1e93745-3528-461e-87de-28554d1810be</paymentAccountID>
<details>
<detail xsi:type="keyStringValuePair">
<key>accountNumber</key>
<value>7210956515</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerFirstname</key>
<value>Sherlock</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerLastname</key>
<value>Holmes</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerTelephoneNumber</key>
<value>12132378999</value>
</detail>
</details>
</paymentAccount>
</payment>
</initiatePaymentResponse>
Example initiatePaymentResponse for InitiateRefusedByProvider:
<?xml version="1.0" encoding="utf-8"?>
<initiatePaymentResponse xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<payment
xsi:type="paymentWithPaymentAccount">
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShop</shopID>
<paymentMethod>
<key>448</key>
<value>VIPPreferred Redirect Withdrawal</value>
</paymentMethod>
<merchantTransactionID>2a3e6ec3-ab32-4699-8325-bbd975b0ff9d</merchantTransactionID>
<paymentID>8ae8d2c1-2650-4f2f-aaea-1b3dacb407d0</paymentID>
<userID>VIPPreferredWithdrawalExistingPA</userID>
<paymentProvider>
<key>213</key>
<value>Pavilionpay</value>
</paymentProvider>
<amount currencyCode="USD">14.99</amount>
<creationType>
<key>1</key>
<value>User</value>
</creationType>
<userIP>127.0.0.1</userIP>
<state>
<id>ff959b66-16bf-4789-b73d-18333e9fa0aa</id>
<definition>
<key>550</key>
<value>InitiateRefusedByProvider</value>
</definition>
<createdOn>2024-06-20T09:15:33.5826401Z</createdOn>
<paymentStateDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderResponseCode</key>
<value>25</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>ProviderResponseMessage</key>
<value>operatorErrorMessage: Withdrawal amount must be greater than $xx.xx.</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AdditionalProviderResponseMessage</key>
<value>operatorDeclineDescription: Withdrawal amount must be greater than $xx.xx.</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</detail>
</paymentStateDetails>
</state>
<isExecuted>false</isExecuted>
<baseAmount currencyCode="EUR">11.26</baseAmount>
<paymentDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderExternalID</key>
<value>10002892</value>
</detail>
</paymentDetails>
<paymentAccount>
<paymentAccountID>d1e93745-3528-461e-87de-28554d1810be</paymentAccountID>
<details>
<detail xsi:type="keyStringValuePair">
<key>accountNumber</key>
<value>7210956515</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerFirstname</key>
<value>Sherlock</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerLastname</key>
<value>Holmes</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerTelephoneNumber</key>
<value>12132378999</value>
</detail>
</details>
</paymentAccount>
</payment>
</initiatePaymentResponse>
Example initiatePaymentResponse for InitiateRequestProviderCommunicationErrorOccurred:
<initiatePaymentResponse xmlns=http://www.cqrpayments.com/PaymentProcessing
xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance>
<payment
xsi:type="paymentWithPaymentAccount">
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShopProvider</shopID>
<paymentMethod>
<key>448</key>
<value>VIPPreferred Redirect Withdrawal</value>
</paymentMethod>
<merchantTransactionID>hc-20240620-104709</merchantTransactionID>
<paymentID>e0916e2d-e57d-457c-9cc8-f58c49095157</paymentID>
<userID>JADLANG1</userID>
<paymentProvider>
<key>213</key>
<value>Pavilionpay</value>
</paymentProvider>
<amount currencyCode="USD">40.01</amount>
<creationType>
<key>1</key>
<value>User</value>
</creationType>
<userIP>127.0.0.1</userIP>
<state>
<id>0e737e7b-1fb5-456f-b0fa-47235df54fd8</id>
<definition>
<key>325</key>
<value>InitiateRequestProviderCommunicationErrorOccurred</value>
</definition>
<createdOn>2024-06-20T08:47:29.5621711Z</createdOn>
<paymentStateDetails>
<detail xsi:type="keyStringValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</detail>
</paymentStateDetails>
</state>
<isExecuted>false</isExecuted>
<baseAmount currencyCode="EUR">30.06</baseAmount>
<paymentDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderExternalID</key>
<value>10002890</value>
</detail>
</paymentDetails>
<paymentAccount>
<paymentAccountID>8a823aca-e95e-4daf-8db3-766cff1351bf</paymentAccountID>
<details>
<detail xsi:type="keyStringValuePair">
<key>accountNumber</key>
<value>7210961825</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerFirstname</key>
<value>JADWIGA</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerLastname</key>
<value>LANGLEY</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerTelephoneNumber</key>
<value>3126123087</value>
</detail>
</details>
</paymentAccount>
</payment>
</initiatePaymentResponse>
InitiateRequestProviderCommunicationError
If the payment reached InitiateRequestProviderCommunicationErrorOccurred state, please restart the payment and send another request.
Redirect to Provider
For testing the basic flow, the merchant needs to invoke the web component.
For easy testing, the merchant can use this basic HTML page:
<html>
<head>
<style>
body{
font-size: 35px;
font-family: Helvetica;
color:#ffffff;
}
.magicpattern {
width: 100%;
height: 100%;
background-size: cover;
background-position: center center;
background-repeat: repeat;
}
.loader {
border: 6px solid #4380ba;
border-radius: 50%;
border-top: 6px solid #60ba69;
width: 50px;
height: 50px;
-webkit-animation: spin 2s linear infinite; /* Safari */
animation: spin 1s linear infinite;
margin:auto;
display: none;
}
@-webkit-keyframes spin {
0% { -webkit-transform: rotate(0deg); }
100% { -webkit-transform: rotate(360deg); }
}
@keyframes spin {
0% { transform: rotate(0deg); }
100% { transform: rotate(360deg); }
}
</style>
</head>
<body class="magicpattern">
<div style="text-align:center;background-color:transparent;"><img src="https://www.vippreferred.com/assets/images/vip-preferred-brand.png"/></div>
<!-- START ACCOUNT LOOKUP DIV -->
<div style="width:30%;margin:20 auto;background-color:#0b0d3e;border-radius: 25px;border:5px solid #efefef22;padding:20px;">
<div style="text-align:center;margin:25px;">
<div style="width:500px;display: inline-block;">
Session ID
</div>
<div>
<input type="text" id="sessionId" style="height:40px;vertical-align:middle;font-size:20px;width:400px;text-align:center;"/>
</div>
</div>
<div style="text-align:center;margin:25px;">
<div style="width:500px;display: inline-block;">
Transaction Type
</div>
<div>
<select type="text" id="mode" style="height:40px;vertical-align:middle;font-size:20px;">
<option>withdraw</option>
<option>deposit</option>
</select>
</div>
</div>
<div style="text-align:center;">
<button onclick="run()" style="width:150px;height:40px;vertical-align:middle;font-size:20px; width:250px;margin:15px;" id='accountButton'>
Submit
</button>
<div class="loader" id="accountLoader"></div>
</div>
</div>
<script>
function run() {
const windowFeatures = "popup=true,width=500,height=850";
var win = window;
win.open('https://cert.api-gaming.paviliononline.io/sdk?mode='+document.getElementById('mode').value+'#'+document.getElementById('sessionId').value, "_blank",windowFeatures);
win.addEventListener('message', function(e){
if(e.data==='close')
{
window.alert('close');
}
});
}
</script>
</body>
</html>
Provider screenshots
After the VIP Preferred SDK is invoked, the user will see the following for withdrawals (disbursements):

The customer may select the displayed bank account and click "Withdraw", or he may add additional bank accounts or administer the list of available bank accounts:

After selecting a bank account and clicking "Withdraw", the following screen is displayed:

Intermediate notification
After the VIP Preferred web SDK has been invoked, the merchant will be notified about the intermediate result of the withdrawal.
The detail InstantPaymentEligible indicates if patron is eligible for an instant payment and if merchant is supported this.
The standard notification mechanism is used for notifying the merchant in the background (asynchronously) about payment state changes. For more information see PaymentStateChangedNotification.
PaymentStates | Description |
---|---|
ApprovedByProvider | The payment has been approved by the provider and is ready for execution. |
RefusedByProvider | An error occurred |
AbortedByCustomer | The payment was aborted by the customer on the VIP Preferred web SDK. |
Example handlePaymentStateChangedNotificationRequest (for ApprovedByProvider state):
<?xml version="1.0" encoding="utf-16"?>
<handlePaymentStateChangedNotificationRequest xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance>
<payment
xmlns:q1=http://www.cqrpayments.com/PaymentProcessing
xsi:type="q1:paymentWithPaymentAccount">
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShop</shopID>
<paymentMethod>
<key>448</key>
<value>VIPPreferred Redirect Withdrawal</value>
</paymentMethod>
<merchantTransactionID>2cc12b01-0834-4434-8962-34e4eb16f02b</merchantTransactionID>
<paymentID>630675c1-72ee-41fb-bd27-4f98079036a6</paymentID>
<userID>VIPPreferredWithdrawalExistingPA</userID>
<paymentProvider>
<key>213</key>
<value>Pavilionpay</value>
</paymentProvider>
<amount currencyCode="USD">10.0100</amount>
<creationType>
<key>1</key>
<value>User</value>
</creationType>
<userIP>127.0.0.1</userIP>
<state>
<id>609b5b33-e428-41ae-997a-2646affe70ed</id>
<definition>
<key>356</key>
<value>ApprovedByProvider</value>
</definition>
<createdOn>2024-06-20T09:37:20.043</createdOn>
<paymentStateDetails>
<detail xsi:type="keyIntValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</detail>
</paymentStateDetails>
</state>
<isExecuted>false</isExecuted>
<baseAmount currencyCode="EUR">7.5200</baseAmount>
<paymentDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderExternalID</key>
<value>10002898</value>
</detail>
<detail xsi:type="keyBooleanValuePair">
<key>InstantPaymentEligible</key>
<value>false</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>DeliveryType</key>
<value>Unknown</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>BankName</key>
<value>Tri-Rivers Fcu</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>ClientIP</key>
<value>84.115.216.20</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>RoutingNumber</key>
<value>262276575</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>UnmaskedAccountNumber</key>
<value>1111112877</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>MaskedAccountNumber</key>
<value>******2877</value>
</detail>
</paymentDetails>
<paymentAccount>
<paymentAccountID>d1e93745-3528-461e-87de-28554d1810be</paymentAccountID>
<details>
<detail xsi:type="keyStringValuePair">
<key>accountNumber</key>
<value>7210956515</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerFirstname</key>
<value>SHERLOCK</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerLastname</key>
<value>HOLMES</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerTelephoneNumber</key>
<value>12132378999</value>
</detail>
</details>
</paymentAccount>
</payment>
</handlePaymentStateChangedNotificationRequest>
Once the notification for state ApprovedByProvider has been sent to the merchant, the state is updated to PendingOnConfirmation.
Example handlePaymentStateChangedNotificationRequest (for AbortedByCustomer state):
<?xml version="1.0" encoding="utf-16"?>
<handlePaymentStateChangedNotificationRequest xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance>
<payment
xmlns:q1=http://www.cqrpayments.com/PaymentProcessing
xsi:type="paymentWithPaymentAccount">
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShop</shopID>
<paymentMethod>
<key>448</key>
<value>VIPPreferred Redirect Withdrawal</value>
</paymentMethod>
<merchantTransactionID>68af15b3-fba7-4502-b80a-1208b4a7940b</merchantTransactionID>
<paymentID>5a755de8-7503-4db9-823c-2361ec5cabc4</paymentID>
<userID>VIPPreferredWithdrawalExistingPA</userID>
<paymentProvider>
<key>213</key>
<value>Pavilionpay</value>
</paymentProvider>
<amount currencyCode="USD">10.0200</amount>
<creationType>
<key>1</key>
<value>User</value>
</creationType>
<userIP>127.0.0.1</userIP>
<state>
<id>b91bc30c-072b-4a67-a040-267c9620d761</id>
<definition>
<key>101</key>
<value>AbortedByCustomer</value>
</definition>
<createdOn>2024-06-20T17:00:24.6</createdOn>
<paymentStateDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderResponseCode</key>
<value>1000</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>ProviderResponseMessage</key>
<value>User Exited Flow.</value>
</detail>
<detail xsi:type="keyIntValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</detail>
</paymentStateDetails>
</state>
<isExecuted>false</isExecuted>
<baseAmount currencyCode="EUR">7.5300</baseAmount>
<paymentDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderExternalID</key>
<value>10002998</value>
</detail>
</paymentDetails>
<paymentAccount>
<paymentAccountID>d1e93745-3528-461e-87de-28554d1810be</paymentAccountID>
<details>
<detail xsi:type="keyStringValuePair">
<key>accountNumber</key>
<value>7210956515</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerFirstname</key>
<value>Sherlock</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerLastname</key>
<value>Holmes</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerTelephoneNumber</key>
<value>12132378999</value>
</detail>
</details>
</paymentAccount>
</payment>
</handlePaymentStateChangedNotificationRequest
Example handlePaymentStateChangedNotificationRequest (for RefusedByProvider):
<?xml version="1.0" encoding="utf-16"?>
<handlePaymentStateChangedNotificationRequest xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance>
<payment
xmlns:q1=http://www.cqrpayments.com/PaymentProcessing
xsi:type="paymentWithPaymentAccount">
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShop</shopID>
<paymentMethod>
<key>448</key>
<value>VIPPreferred Redirect Withdrawal</value>
</paymentMethod>
<merchantTransactionID>6719ac99-6d5d-4d26-950d-69686070d543</merchantTransactionID>
<paymentID>f87bb80e-9cd3-4bc1-a280-171a6a49f367</paymentID>
<userID>VIPPreferredWithdrawalExistingPA</userID>
<paymentProvider>
<key>213</key>
<value>Pavilionpay</value>
</paymentProvider>
<amount currencyCode="USD">10.0200</amount>
<creationType>
<key>1</key>
<value>User</value>
</creationType>
<userIP>127.0.0.1</userIP>
<state>
<id>83b8389b-68fe-43e7-92ef-8f490e613d42</id>
<definition>
<key>100</key>
<value>RefusedByProvider</value>
</definition>
<createdOn>2024-06-20T16:56:10.933</createdOn>
<paymentStateDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderResponseCode</key>
<value>92</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>ProviderResponseMessage</key>
<value>Duplicate transaction detected but bank routing number does not match.</value>
</detail>
<detail xsi:type="keyIntValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</detail>
</paymentStateDetails>
</state>
<isExecuted>false</isExecuted>
<baseAmount currencyCode="EUR">7.5300</baseAmount>
<paymentDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderExternalID</key>
<value>10002997</value>
</detail>
</paymentDetails>
<paymentAccount>
<paymentAccountID>d1e93745-3528-461e-87de-28554d1810be</paymentAccountID>
<details>
<detail xsi:type="keyStringValuePair">
<key>accountNumber</key>
<value>7210956515</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerFirstname</key>
<value>Sherlock</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerLastname</key>
<value>Holmes</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerTelephoneNumber</key>
<value>12132378999</value>
</detail>
</details>
</paymentAccount>
</payment>
</handlePaymentStateChangedNotificationRequest>
Final approval or abort by the merchant
When the merchant is ready to execute the payment and pass the funds to the users wallet, the merchant should call excutePaymentAction call with action 50010 (accept) or action 152 (abort).
When sending the executePaymentAction request, the merchant has to send a detail FundTransferType.
InstantPaymentEligible | Available FundTransferType options |
---|---|
true | SDA (Same Day) and INP (Instant Payment) |
false | ACH |
The following states can be returned in executePaymentActionResponse:
State | Description |
---|---|
AbortedOnProvider (397) | Withdrawal is not executed. |
WithdrawnByProvider (20) | The withdrawal payment is executed successfully. |
WithdrawErrorReportedByProvider (21) | Some data sent in the withdrawal request was incorrect or missing. Please check with PXP merchant support. |
RefusedByProvider (100) | The withdrawal payment was refused by provider. |
Merchant aborts withdrawal - executePaymentActionRequest:
<executePaymentActionRequest xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShop</shopID>
<paymentID>18bec409-3a02-48c3-b92c-c23c323a5bae</paymentID>
<actionID>152</actionID>
<actionData>
<data xsi:type="keyStringValuePair">
<key>PaymentID</key>
<value>18bec409-3a02-48c3-b92c-c23c323a5bae</value>
</data>
</actionData>
</executePaymentActionRequest>
Merchant aborts withdrawal - executePaymentActionResponse:
< executePaymentActionResponse
xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<statusCode>1</statusCode>
<actionResults>
<result xsi:type="keyStringValuePair">
<key>lastStateDefinition</key>
<value>397</value>
</result>
<result xsi:type="keyStringValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</result>
</actionResults>
</executePaymentActionResponse>
Merchant approves withdrawal - executePaymentActionRequest:
<executePaymentActionRequest xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShop</shopID>
<paymentID>f6835c89-fc1a-4f5a-82e4-b10eb7456a86</paymentID>
<actionID>50010</actionID>
<actionData>
<data xsi:type="keyStringValuePair">
<key>PaymentID</key>
<value>f6835c89-fc1a-4f5a-82e4-b10eb7456a86</value>
</data>
<data xsi:type="keyStringValuePair">
<key>FundTransferType</key>
<value>ACH</value>
</data>
</actionData>
</executePaymentActionRequest>
Merchant approves withdrawal - executePaymentActionResponse:
<executePaymentActionResponse xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<statusCode>0</statusCode>
<actionResults>
<result xsi:type="keyStringValuePair">
<key>lastStateDefinition</key>
<value>20</value>
</result>
<result xsi:type="keyStringValuePair">
<key>BankName</key>
<value>Tri-Rivers Fcu</value>
</result>
<result xsi:type="keyStringValuePair">
<key>ClientIP</key>
<value>84.115.216.20</value>
</result>
<result xsi:type="keyStringValuePair">
<key>RoutingNumber</key>
<value>262276575</value>
</result>
<result xsi:type="keyStringValuePair">
<key>UnmaskedAccountNumber</key>
<value>1111112877</value>
</result>
<result xsi:type="keyStringValuePair">
<key>MaskedAccountNumber</key>
<value>******2877</value>
</result>
</actionResults>
</executePaymentActionResponse>
Merchant approves withdrawal - executePaymentActionResponse with state WithdrawErrorReportedByProvider:
<executePaymentActionResponse xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<statusCode>0</statusCode>
<actionResults>
<result xsi:type="keyStringValuePair">
<key>lastStateDefinition</key>
<value>21</value>
</result>
<result xsi:type="keyStringValuePair">
<key>ProviderErrorResponseCode</key>
<value>400</value>
</result>
<result xsi:type="keyStringValuePair">
<key>ProviderErrorResponseMessage</key>
<value>"'Home Phone Number' must not be empty."</value>
</result>
<result xsi:type="keyStringValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</result>
</actionResults>
</executePaymentActionResponse>
Merchant approves withdrawal - executePaymentActionResponse with state RefusedByProvider:
<executePaymentActionResponse xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<statusCode>0</statusCode>
<actionResults>
<result xsi:type="keyStringValuePair">
<key>lastStateDefinition</key>
<value>100</value>
</result>
<result xsi:type="keyStringValuePair">
<key>ProviderErrorResponseMessage</key>
<value>WithdrawApproval has FAILED because the bank account was not found with Transaction Id: 234623462346.</value>
</result>
<result xsi:type="keyStringValuePair">
<key>PaymentStateReasonID</key>
<value>1</value>
</result>
</actionResults>
</executePaymentActionResponse>
Test data
Please contact PXP for test data.
Withdrawal Returns
If withdrawal payments are returned, PXP Financial will send a notification to the merchant.
A notification for ReturnedByProvider state of payment method VIPPreferred Redirect Withdrawal Return is sent.
The following paymentDetails are included in the notification:
Detail (Type) | Description |
---|---|
ProviderExternalID (string) | ProviderExternalID set by PXP |
SettlementCurrencyCode (integer) | defaults to 840 (USD) |
CustomerName (string) | Customer name |
Reason (string) | Reason for Return |
SettlementAmount (decimal) | Amount |
OriginalPaymentID (string) | PaymentID of the original withdrawal payment |
OriginalPaymentMerchantTransactionID (string) | MerchantTransactionID of the original withdrawal payment |
OriginalPaymentID (string) | PaymentID of the original withdrawal payment |
OriginalPaymentMethodName (string) | Payment method name of the original withdrawal payment, thus VIPPreferred Redirect Withdrawal |
Return Reasons:
- Account Closed
- No Account / Unable to Locate
- Invalid Account Number
- Credit Entry Refused By Receiver
Additional return reasons might be added by PavilionPay.
Sample handlePaymentStateChangedNotificationRequest:
<handlePaymentStateChangedNotificationRequest xmlns:xsd=http://www.w3.org/2001/XMLSchema
xmlns:xsi=http://www.w3.org/2001/XMLSchema-instance
xmlns=http://www.cqrpayments.com/PaymentProcessing>
<payment
xsi:type="paymentWithPaymentAccount">
<merchantID>B2BTestMerchant</merchantID>
<shopID>VIPPreferredRedirectDepositShop</shopID>
<paymentMethod>
<key>453</key>
<value>VIPPreferred Redirect Withdrawal Return</value>
</paymentMethod>
<merchantTransactionID>1923f6ab-2b94-4faa-8e17-50bb267eb9a9</merchantTransactionID>
<paymentID>4f67e542-6a6e-4fa2-8a90-c379f35e7d5c</paymentID>
<userID>VIPPreferredWithdrawalExistingPA</userID>
<paymentProvider>
<key>213</key>
<value>Pavilionpay</value>
</paymentProvider>
<amount currencyCode="USD">500.0100</amount>
<creationType>
<key>6</key>
<value>Provider</value>
</creationType>
<state>
<id>e944eb3b-399e-41db-be2d-c486cc775979</id>
<definition>
<key>279</key>
<value>ReturnedByProvider</value>
</definition>
<createdOn>2024-07-15T16:50:51.743</createdOn>
<paymentStateDetails xsi:nil="true"/>
</state>
<isExecuted>true</isExecuted>
<baseAmount currencyCode="EUR">375.6900</baseAmount>
<paymentDetails>
<detail xsi:type="keyStringValuePair">
<key>ProviderExternalID</key>
<value>536707cb-48e3-4c97-92db-db1a991852dc</value>
</detail>
<detail xsi:type="keyIntValuePair">
<key>SettlementCurrencyCode</key>
<value>840</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>CustomerName</key>
<value>MALONE,DAVID</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>Reason</key>
<value>CREDIT ENTRY REFUSED BY RECEIVER</value>
</detail>
<detail xsi:type="keyDecimalValuePair">
<key>SettlementAmount</key>
<value>500.010000000</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>OriginalPaymentID</key>
<value>d3f6ccd8-0ff2-4c44-941e-3ff35bf7c00d</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>OriginalPaymentMerchantTransactionID</key>
<value>1923f6ab-2b94-4faa-8e17-50bb267eb9a9</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>OriginalPaymentMethodID</key>
<value>448</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>OriginalPaymentMethodName</key>
<value>VIPPreferred Redirect Withdrawal</value>
</detail>
</paymentDetails>
<paymentAccount>
<paymentAccountID>d1e93745-3528-461e-87de-28554d1810be</paymentAccountID>
<details>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerFirstname</key>
<value>Sherlock</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerLastname</key>
<value>Holmes</value>
</detail>
<detail xsi:type="keyStringValuePair">
<key>AccountOwnerTelephoneNumber</key>
<value>12132378999</value>
</detail>
</details>
</paymentAccount>
</payment>
</handlePaymentStateChangedNotificationRequest>
Updated 23 days ago
